P374 Intrinsically Safe Color Video Inspection System

The Mini Flexiprobe system sets new standards by offering an intrinsically safe solution that allows successful inspection and reporting within Zone O environments.

Overview

Pearpoint's P374 IS is an intrinsically safe pushrod system certified to EEX ia IIC T6 for Zone 0 Hazardous environments such as vessels or pipework within the chemical and petrochemical industries, landfill venting systems, natural gas supply infrastructure, etc. The surface equipment is IP55 rated allowing this system to be used in most types of weather conditions. The P374 IS system is compact and fully integrated making it very easy to transport around.

 FEATURES / BENEFITS:

25mm (1”) to 100mm (4”) Pipe Inspections

61 Meters (200 ft) of semi rigid rod

Intrinsically safe system certified to EE x ia IIC T6 for Zone 0 Hazardous environments

True portability, weighs only 21kg (46lbs) and operates from a 12V DC external supply

Composite video output/input allowing connection to a video recorder or external monitor

Integrated high resolution 6.4” Color LCD allowing improved image recognition, retractable sun visor built in reducing the effects of sunlight on the screen

QWERTY Keyboard for text annotation on site, with 9 pages of user defined text available, 9 programmable user defined fields enabling faster text generation

A truly waterproof system for operation in most weather conditions, protected to Environmental spec IP55

CMOS camera technology allowing increased operating time through low power consumption

Maintenance free, White LED’s for increased performance and reliability

Integral electronic meterage counter that displays distance on screen in 0.1m increments which is accurate to +/- 1%

TECHNICAL SPECIFICATIONS:

CAMERA & LIGHTHEAD

Diameter • 24mm (0.94″)

Full Diameter Length • 17mm (0.67″)

Total length • 31mm (1.22″)

Material • 300 Series Stainless Steel and Epoxy Resin Potted Lighthead

Focal Length • 6.35mm (0.25″) to infinity, manually adjustable

Power consumption • 100mA

Sensor Transfer Type • CMOS

Active Pixel Matrix • 510 x 492

Horizontal resolution • 360TVL per picture height

Sensitivity • 3 lux

Viewing angle • 44 o

Voltage • 21v max

Waterproofing • IP68 11Bar (160psi)

CONTROL UNIT & COILER

Weight • 46lbs (21kg)

Voltage • Auto Sensing 110v – 240v or 12v DC

Consumption Unit • 3w

Waterproofing • IP55

Video output • Composite

Video input • Composite

Height • 900mm (35.4”)

Width • 600mm (23.6”)

Depth • 300mm (12”)

Approvals • CE and FCC compliant

ATEX Borescope



Call For Configuration Options

Categories Pipe Inspection Systems (Push Camera and Sewer Camera) , Hazardous Environment Borescopes
